EJB14040 - Square D 30 Amp 1 Pole 277 Volt Bolt-On Circuit Molded Case Breaker
EJB14040 - Square D 30 Amp 1 Pole 277 Volt Bolt-On Circuit Molded Case Breaker

EJB14040 - Square D - Molded Case Circuit Breaker

$463.99
$463.99
Please hurry! Only 1000 left in stock
Limited-Time Offers, End in: 151D 8H 23M 0S
Condition: New
Subtotal: $463.99

Free Shipping

Free Shipping on $60 or More!

Return & Exchange

you may return it for REFUND or EXCHANGE it for

another style within 30 days of receiving your order.
EJB14040 - Square D 30 Amp 1 Pole 277 Volt Bolt-On Circuit Molded Case Breaker

EJB14040 - Square D - Molded Case Circuit Breaker

$463.99
EJB14040 - Square D 30 Amp 1 Pole 277 Volt Bolt-On Circuit Molded Case Breaker

EJB14040 - Square D - Molded Case Circuit Breaker

$463.99
Condition: New
Description
Description
x

Overview

Product Specifications - EJB14040 - Square D Bolt-On Circuit Breaker

  • Part Number:

    EJB14040

  • Manufacturer:

    Schneider Electric / Square D

  • Family:

    EJB Series

  • Pole:

    1

  • Amp

    40

  • Volt:

    277

  • Phase:

    1

  • Category:

    Molded Case / 1-Pole

  • Connection:

    Bolt-On

  • Type:

    EJB

  • Functions:

    LI - Long-Time and Instantaneous

  • Protection:

    Thermal Magnetic

  • AIC Ratings:

    65kA@277V | 65kA@240V | 100kA@120V

Dimensions

  • Dimensions (HxWxD):

    5.66" x 0.98" x 4.05"

  • Weight:

    2lbs

Standards

CSA Approved logo

Additional Details

  • Protection Type:

    Short-Circuit / Overload

  • Module Type:

    E-Frame

  • Trip Unit Rating:

    875 Amp

  • Line Rated Current:

    40 Amp

  • Maximum Operating Voltage:

    277 V AC

  • Mounting Mode:

    Bolt-On

  • Product Destination:

    Square D NF Panelboard

  • Electrical Connection:

    Aluminum Lugs

  • Holding Current:

    270 Amp

  • Local Signaling:

    Trip Indicator

  • Circuit Breaker Application:

    HID-Rated / HACR-Rated

  • AWG Gauge:

    AWG 12...AWG 6 Aluminum | AWG 14...AWG 6 Copper

Product Description - EJB14040 - Square D Bolt-On Circuit Breaker

Schneider Electric / Square D's EJB14040 bolt-on molded case circuit breaker is a reliable and easy-to-install device designed for use in Square D NF Panelboards. This circuit breaker is CSA-rated, HID-rated and HACR-rated, and UL Listed as High-Intensity Discharge.

The EJB14040 is a 1-pole bolt-on circuit breaker, rated at 40A at a system voltage of 277V AC. The circuit breaker has a thermal-magnetic trip unit and a signal indicator to indicate when a trip occurred. The device has a hold current of 270A (the maximum current the breaker can be held at to ensure a trip will occur) and a trip current of 875A (the current value when the breaker is guaranteed to trip).

Square D's EJB14040 circuit breaker is calibrated for 40 degrees C and has aluminum lugs with a terminal lug rating of AWG 12...AWG 6 (aluminum) and AWG 14...AWG 6 (copper).
